Upper room UV germicidal irradiation with LEDs and VIOLET-12X1-O

If you can't find the information you need here, please contact us for more guidance.

UR-UVGI(-LED)

Upper room ultraviolet germicidal irradiation (with light-emitting diodes) + LEDiL VIOLET

Downlight luminaire under VIOLET is 40 cm wide, and VIOLET lens surface is around 15 cm from the edge.

Typically considered eye-safe value for 8 hour exposure: 0.3uW/cm2

Source: https://www.ncbi.nlm.nih.gov/pmc/articles/PMC2099326/

SETUP:

Application:

UR-UVGI(-LED)

Optics:

Optics efficiency:

71 %

LED:

7070 package size UVC LED (280 nm)

Total UV-C output/VIOLET-O:

526 mW

Total power/12 LEDs:

24 W

VIOLET installation height:

2.9 m

Tilt:

5° upwards

Room size:

8 x 10 x 3.5 m

Surface reflectance:

10 %

RESULTS:

UPPER AIR (3.1 m):

Max: 70.2 µW/cm²

EYE LEVEL (1.7 m):

Max:0.3 µW/cm²
